Ductile Cast Iron Hand wheel Resilient Seated Water Seal Gate Valve

This valve widely applied in the liquid pipes for opening or closing fixing in such water, sewage disposal, electric power, energetics pipe , chemical, shipping, energy sources etc.

Standard DIN 3352-F4 ,DIN 3352-F5, BS5163, AWWA C509 ,AWWA C515 Flange drilling is according to DIN2501, BS4504 and ANSI B16.1 PN10,PN16,PN25
Type Flanged End , Socked End ,Mechanical Joint, non rising stem / rising stem
Material Body: Ductile iron GGG40/50 or Cast IronGG25 Wedge : Ductile iron GGG40/50+EPDM/NBR or metal seated Stem: stainless steel 2Cr13 , SS304,SS316 Bolt and Nuts : Carbon Steel with zinc plated or SS304,316
Coating Internal and external with fusion bonded epoxy coating min250μm

    Product Detail

    Application General
    Place of Origin Shanxi, China
    Power Manual
    Structure Gate
    Customized support OEM, ODM
    Port Size Standard
    Warranty 1 years
    Model Number Gate valve
    Temperature of Media Medium Temperature
    Brand Name XINBAODA
    Media Base
    color blue
    Product name resilient seat gate valve
    Size DN50 ~ DN600
    Pressure PN10, PN 16
    Temperature -20 ~120 C
    operator hand wheel
    Seal Surface Wedge Gate Valve
    Standard DIN/BS/AWWA
    Body cast iron painted with epoxy
    Connection Flange Ends

    Packaging and Delivery

    Packaging Details Carton for each item, wooden boxes outside
    Port Xingang,Qingdao

    Supply Ability

    Supply Ability 10000 Piece/Pieces per Month Gate Valve

    Applicable Standards

    Seal Gate Valve (1)fg0
    a.American Standard
    Design to ANSI/AWWA C509
    Face to face dimension to ASME B16.10-2000(ISO 3 series)
    Flange and drilling To SME/ANSI B16.42-1998
    b.British Standard
    Design to BS5163,BS5150
    Face to face dimension to BS5163(ISO 3series,ISO19 series)
    Flange and drilling To BS4504 part1(EN1092)
    c.Germany Standard
    Design to DIN3352
    Face to face dimension to DIN3202(F4:ISO 14 series;F5: ISO 15 series)
    Flange and drilling to BS EN1092
    DN L D D1 D2 b f n-d H W
    50 178 150 114 90 18 3 4-18 270 180
    65 190 165 127 103 18 3 4-18 280 180
    80 203 185 146 122 18 3 4-18 290 200
    100 229 215 178 154 20 3 4-18 315 200
    150 267 280 235 211 23 3 8-18 410 280
    200 292 335 292 268 23 3 8-18 515 320
    225 330 405 324 300 24 3 8-18 560 320
    250 330 405 356 328 24 3 8-22 605 320
    300 356 455 406 378 30 4 12-22 695 450
    350 381 525 470 438 33 4 12-26 790 450
    375 406 580 795 463 33 4 12-26 880 450
    400 406 580 521 489 33 4 12-26 970 560
    450 432 640 584 552 33 4 12-26 1045 560
    500 457 705 641 609 35 4 16-26 1120 800
    600 508 825 756 720 42 5 16-30 1320 800

    Product Display

    Seal Gate Valve (3)rxx
    Seal Gate Valve (4)t6m
    Seal Gate Valve (2)l4p
